XEF 250 Trail

XEF 250 Trail

Fantic TL 250 is the perfect combination of power and ease of riding.

The advanced technology and the continuous research for improvement, make it ideal to ride on the most difficult enduro tracks, but it will permit your skills to develop for an easier ride.

Nothing will ever seem unreachable, relying completely on the performance and intuitive chassis of a motorcycle designed and built entirely in Italy.

An exciting enduro bike, easy and with very low maintenance. Updated aesthetics, inspired by the Fantic Racing models.

zoom
ENGINE

The new Fantic TL 250 is equipped with a 250cc 4-stroke liquid-cooled engine with electronic fuel injection and a brand new ECU, Arrow exhaust and silencer.

CHASSIS

The CrMo steel perimeter frame of the TL 250 has been optimized in terms of rigidity thanks to the placement of new reinforcements for the benefit of performance.

The TL 250 is equipped with a FANTIC FRS 43mm USD racing-derived fork, and FANTIC FRS 250 Piggyback monoshock - preload and hydraulic adjustment.

The swingarm is made of aluminum with variable section and removable rear sub-frame.

Enduro tires 90/90x21 - 120/90x18 mounted on aluminum rims. Powerful and modular 260mm front and 220mm rear wave brake disks.

EQUIPMENT

The TL 250 is the bike for those who want to challenge themselves on technical off-road enduro trails, with similar components to the Racing models.

The equipment includes 43mm Red Fantic FRS front fork, FSR rear suspension with piggy back, preload and hydraulic adjustment, aluminum swingarm, anodized rear brake master cylinder protection, CNC machined triple clamps, racing brake system with adjustable reach, black anodized silencer, handguards, and lightweight ergal crown.

The new front mask mounts a full-LED headlight.

Specifications
ENGINE
Engine: Single cylinder 4 strokes Euro5, liquid cooled
Maximum Torque: 18,6 Nm to 6.750 rpm
Displacement: 249.6 cc
Bore: 77 mm
Stroke: 53.6 mm
Distribution: SOHC 4-valve
Ignition: Electronic
Starter: Electric
Gears: 6
Clutch: Wet multidisc
Exhaust: Manifold and Muffler Euro5 by ARROW
Fuel consumption: 65.4 miles per gallon
CO2 Emission : 135 g/mille

See more

CHASSIS
Frame: Perimeter frame steel CrMo
Sub frame: Removable in aluminium
Swingarm: Aluminium, variable section and progressive link
Tires: 90/90x21 - 120/90x18
Wheels: Aluminium, black anodized
Brakes: Disc “Wave” ø260mm - Disc “Wave” ø220mm
Triple clamps: Aluminum, CNC racing triple clamps
Front suspension: FANTIC FRS ø43mm USD, racing setup, forged aluminium fork bottoms
Rear suspension: FANTIC FRS 125 Piggyback – preload and hydraulic regulation
Handlebar: ø28 aluminum

See more

OVERALL DIMENSIONS
Length: 82.7 in
Seat height: 36.0 in
Wheelbase: 56.0 in
Dry weight: 269 lbs
Fuel tank: capacity 2.0 gal

See more

Consult our technical data
